國家光電ONation

  • 國家光電ONation 以服務日本高度競爭市場起家，專注於提供高品質的顯示器面板，主力為7吋至21.5吋等中型尺寸的顯示器面板及模組，提供客製化模組的服務，為您的產品量身打造。
  • 8.4" OT084AXWDLVH0 1024x768 可完全取代三菱8.4"產品
  • 10.4" OT104AXWDLVH0 1024x768 高亮度1000nits
  • 12.1" OT121EXWDLLH0 1024x768 高亮度1000nits
  • 15.1" OT150CXDDLV-H1 1024x768 高亮度1000nits
產品規格
SizeResolutionPart No.InterfaceBrightnessTFT TypeOperation Temp.AAOD
2.8"240x320OT028AQUDDN-01MCU200TN43.2*57.650*69.2*2.4
3.5"320x240OT035AQDDDN-02TTL380TN70.08*52.5676.9*63.9*3.9
4.3"480x272OT043AWDDDT-03TTL450TN113.5*73.0*6.595.04*53.856
7"800*480OT070QGDDLV00LVDS1000TN-20°C~70°C152.4*91.44165*106*4.8
7"800*480OT070MADDLV-10LVDS1000TN-20°C~60°C153*90165.75*105.39*5.0
8"800*600OT080FSDDDV-H0TTL1000TN-20°C~70°C162*121.5183*141*10.3
8"1024*768OT080IA03LVDS350IPS-20°C~60°C162.05*121.54174.0*136.0*2.5
8.4"800*600OT084DSUDLV-00LVDS 18bits400TN-20°C~70°C170.4*127.8203*145.9*5.7
8.4"800*600OT084HSUDLV-00LVDS 24bits800TN-20°C~70°C170.4*127.8203*145.9*5.7
8.4"800*600OT084ISUDLV-03LVDS 24bits600TN-20°C~70°C170.4*127.8199.5*149.0*9.75
8.4"800*600OT084ISUDLV-02LVDS 24bits1000TN-20°C~70°C170.4*127.8199.5*149.0*9.75
8.4"1024*768OT084AXWDLV00LVDS600IPS-30°C~80°C170.8*128.1199.5*149.0*9.8
8.4"1024*768OT084AXWDLV00LVDS1000IPS-30°C~80°C170.8*128.1199.5*149.0*9.8
9"800x480OT090EGDDLT-00LVDS400TN-20°C~70°C198*111.696210.7*127.065*15
9.7"1024*768OT097IA14LVDS450IPS-10°C~50°C196.6*147.45210.16*164.25*2.85
10.1"1280x800OT0101IA13LVDS300IPS0°C~50°C216.51*135.6229.51*149.1*2.48
10.1"800x1280OT101ZPHMWNMIPI400MIPI-10°C~50°C135.36*216.58143*228.6*2.50
10.1"1200x1920QT10121035-00MIPI400MIPI-10°C~50°C135.36*216.58143.0*228.6*2.6
10.1"1920x1200OT101ZEWDLNH0LVDS1000IPS-10°C~50°C216.81*135.5229.46*149.1*4.6
10.4"1024x768OT104KXWDLV00LVDS600IPS-20°C~70°C211.2*158.4236*174.3*10.6
10.4"1024x768OD104KXWDLVH0LVDS1000IPS-20°C~70°C211.2*158.4236*174.3*10.6
12.1"1024 x768OT121EXWDLL-00LVDS1000IPS-30°C~85°C 245.76*184.32279.0*209.0*9.0
12.1"1280x800OT121ZBWDLV-00LVDS400IPS-20°C~70°C261.12*163.2278.0*184.0*10.0
15"1024*768OT150CXDDLV-H1LVDS1000TN-20°C~70°C304.128*228.096326.5*253.5*15.66
15.6"1920*1080OT156ZBWDLN-00LVDS450IPS-30°C~85°C344.16*193.59363.8*215.9*9.3
18.5"1366x768OT185ZOWDLN-00LVDS1000TN-20°C~70°C409.8*230.4430.0*254.6*16.4
21.51920*1080OT215BFWDLV-H0LVDS400IPS0°C~50°C476.64*268.11495.6*292.2*19.56
21.51920*1080OT215ZFWDLV00LVDS1000IPS-20°C~70°C476.64*268.11495.6*292.2*19.56
